MOPA 20 Watt 30 Watt Fiber Laser Marking Machine For Engraving Stainless Steel colors
Fiber laser marking machine is one of the most advanced laser marking equipment in the world
nowadays.
It adopts the third generation (the most advanced) solid-state fiber laser to create the super fine effect of marking. This machine has very wide application. It can mark on all metals and some plastic, ceramic.
Applicable material:
Metals (including rare metals), engineering plastics, electroplating materials, coating materials,coating materials, plastics, rubber, epoxy resin, ceramic, plastic, ABS, PVC, PES, steel, titanium, copper and other materials.
Applicable industry:
Mobile phone keypad, plastic translucent keys, electronic components, integrated circuits (IC), electrical appliances, communication products, sanitary ware, tools, accessories, knives, eyeglasses and clocks, jewelry, auto parts, luggage buckle, cooking utensils, stainless steel products and other industries.
Advantages:
High speed 2-3 times over than traditional diode pumped marking machine
Air-cooling smart machine size
Good scan head, with good seal, small volume, and compact
ast Speed. The maximum marking speed can reach to 7000mm/s . 800 standard characters per second, is 3 to 5 times above that of traditional products.
Main specification:
| Laser power | 10W/ 20W/ 30W / 50W |
| Wavelength | 1064nm |
| Beam quality | <1.5 |
| Output power | 10% ~ 100% continuously to be adjusted |
| Output frequency | 20 KHz ~ 100KHz continuously to be adjusted |
| Power stability | < ±1% rms |
| Focus spot diameter | <0.01mm |
| Matching size | 50mm*50mm / 110mm*110mm / 175mm*175mm |
| Carving depth | ≤1.2mm |
| Carving speed | 800 standard characters / second |
| Minimum line width | 0.012 mm |
| Minimum character | 0.15mm |
| Repeated accuracy | ± 0.003mm |
| System operation environment | Windows XP/ 2000 / 98 |
| Cooling mode | Air cooling |
| Temperature of operation environment | 15ºC ~ 35ºC |
| Power requirement | 220V / single phase / <400W |
| Life of laser module | 100000 Hrs |
Sample show:
Packing and shipping :
1. Durable wooden case or as per required.
2. The delivery lead time would be 5-7 working days after recieving the payment.
3. As for the wholsalers/distributors, we could send the cargo by air, by sea or by railways via reliable forwarder.
Our Services:
1. Providing professional technical support.and Send the product catalog and instruction manual.
2. our technicians will provide on-site service to customers in china. We will supply the whole day online service to foreign customers. According to foreign customer's requirement, we will arrange technicians go abroad to install or maintenance the machine.
3. We promise honest and fair, it's our pleasure to serve you as your purchasing consultant.
4. High quality laser path suitable for delicate marking.
5. after the expiry of warranty, we can renewal of the contract, which can enjoy the same service as that during the warranty period.
6.A large stock of components and parts, easily-worn parts.
About us
Wuhan Linxuan Laser Co., Ltd is a high-tech enterprise in Wuhan East Lake Development Zone , we are specializing in producing,developing and selling laser marking machine,laser welding machine,laser cutting machine,etc.It is Chinese industrial laser processing equipment pioneer ,domestic well-known marking equipment manufacturer.And,with rich experience ,we also have obtained huge success in international market ,the mainly foreign markets are United States, Germany, Spain, Russia, Singapore, Indonesia...more than 30 countries and regions .Till now, a lot of customers all over the world have visited us.
