Micro Pencil Large Working Size Co2 laser Engraving Machine For Garment Industry
Product Features
1. The imported linear guide way ensures the high precision and the long service.
2. Economic, cost-effective multi-functional laser cutting machine
3. Five reflection mirrors and one lens design to ensure stable and constant light path, excellent Reliable product quality and overall cutting ability (multi-functional, applicable for cutting stainless steel, carbon steel, acrylic, MDF, die board).
4. Non-contact metal cutting auto-following device, to cut all kinds of materials with less investment.
Application
Engraving and cutting of paper, fabric, plastic, non-woven cloth in garment and toy industries, also inclusive of precise cutting to non-metal materials,like acrylic and MDF board in handbag, glove, mold, advertisements, decoration, electrical appliance and plastic industries.
Applied Material:
Wood work, paper, leather, cloth, organic glass, resin, acrylic, woolens, plastic, rubber, ceramic, crystal, jade, bamboo and other non-metal materials.
Specifications
| Item: | LX-1390 |
| Laser Type: | CO2 Laser Tube |
| Laser Wavelength: | 10.64um |
| Laser Power: | 60W/80W/100W/130W/150W/180W |
| Working Area: | 600*900mm/1300*900mm/1600*1000mm |
| Engraving Speed: | 0-30000mm/min |
| Cutting Speed: | 0-3600 mm/min |
| Cutting Thickness | 0-10mm (Varies to different materials) |
| Machine Power: | 300-450W |
| Location Type: | Red Pointer positioning |
| Location Accuracy | ±0.1mm |
| Resolution: | 1000dpi |
| Port: | USB 2.0 |
| Working Table: | Honeycomb table |
| Up-down height: | 0-300mm |
| Mini Text Height: | English Letter: 1mm Chinese:2mm |
| Support Software: | Windseal XP / CorelDraw |
| Working Voltage: | AC220V/50HZ AC110V/50HZ |
| Working Environment: | Temperature:0-45℃ Humidity:5%-95% |
| Driver Way: | Digital Subdividing Step Driver |
| Laser Device Cooling Type | Circulating Water Cooling |
| Option Item: | Motorized up-down table, Rotary Fixture Water-circulation Non-normal Protection Switch, CW-3000 Water Chiller |
| Rotary System(Optional) | φ10-150×300mm |
Sample show
Packaging & Delivery
1. Wood case or as per required.
2. The delivery lead time would be 7-15 days against down payment.
3. As for the wholsalers/distributors,we could send the cargo by air, by sea or by railways via reliable forwarder
Competitive Advantages
1. We offer high quality products at competitive price in quick delivery.
2. 100% custom pass guaranteed.
3. Good after-sale service.
4. Flexible and Untraceable payment terms.
Product Tags:
|
|
Micro Pencil CO2 Laser Engraving Cutting Machine 10.64um Wavelength With Large Working Size Images
|
